The HDMI Power Inserter is designed to boost the distance an HDMI signal can be transmitted along an HDMI cable. Generally, household HDMI video equipment uses low power output for short 2~5 metre cable lengths. Over short cable distances, the HDMI signal can rapidly deteriorate to a stage where data is unusable by the receiving HDMI de-multiplexers. The HDMI signal deterioration becomes even worse when high definition resolutions like 720p, 1080i/p and 4K2K are used. Extend signal transmission distance and improve the HDMI signal quality when using the HDMI Power Inserter.
HDMI Power Inserter

HDMI Power Inserter



Made In Taiwan

Product ID : 15381
Price : 63.35 USD (Change Currency)
Available : Stock


  Freight Quote
Contact Staff


The HDMI Power Inserter is designed to boost the distance an HDMI signal can be transmitted along an HDMI cable. Generally, household HDMI video equipment uses low power output for short 2~5 metre cable lengths. Over short cable distances, the HDMI signal can rapidly deteriorate to a stage where data is unusable by the receiving HDMI de-multiplexers. The HDMI signal deterioration becomes even worse when high definition resolutions like 720p, 1080i/p and 4K2K are used. Extend signal transmission distance and improve the HDMI signal quality when using the HDMI Power Inserter.


Unit Dimensions: 4.6 x 4.6 x 2.3 cm Shipping Weight: 1.98 kg
Location: NSW, Australia Item Type: HDMI Converters
Condition: New Warranty : 12 Months
Certificates : CE, CTick, UL Manual : PDF User Manual (168.7 KB)


HDMI Power Inserter - Product Details


Features:

  • Supports HDMI HD, UHD and 3D pass-thru
  • Supports safe power signal separation, isolating the input HDMI signal power
  • Supports up to 5v / 2A
  • In-built 'Over Current Protection' to prevent power surges
  • Lightweight, compact, easy and efficient to use
  • Supports Maximum input + output cable length of 16m@8-bit and 10m@12-bit colour depth

Specifications:

  • Input Port: 1 x HDMI (Female Type 'A')
  • Output Port: 1 x HDMI (Female Type 'A')
  • Max Input Cable Distance: 8m/1080p@8-bit; 5m/1080p@12-bit
  • Max Output Cable Distance: 8m/1080p@8-bit; 5m/1080p@12-bit
  • Power: 100-240vAC to +5vDC 2.6A (US/EU standards; CE/FCC/UL approved)
  • Power Consumption (watts): 0.25w ~ 12w (max)
  • Total Output Power (watts): 12w (max)
  • Dimensions (cms): 4.6(l) x 4.6(d) x 2.3(h)
  • Weight (grams): 30g
  • Chassis: Black Plastic
  • Operating Temperature: 0c ~ 40c / 32f ~ 104f
  • Relative Humidity: 20% ~ 90% RH (non-condensing)
  • ESD protection: Human Body Model: ±8kV (air-gap); ±4kV (contact)

Power Supplies:

  • Multi-Voltage Power Supply : 100 - 240VAC to 5V DC 2.6A Switch Mode Power Supply - Center Positive


Video and Audio Connection Type


Connects From : Connects To :
  • HDMI (HDTV)
  • HDMI (HDTV)


Video and Audio Signal Conversion


Converts From : Converts To :
  • HDTV 480p
  • HDTV 576p
  • HDTV 720p
  • HDTV 1080p
  • HDTV 1080i
  • HDTV 480i
  • HDTV 576i
  • 4K x 2K
  • 3D
  • HDTV 480p
  • HDTV 576p
  • HDTV 720p
  • HDTV 1080p
  • HDTV 1080i
  • HDTV 480i
  • HDTV 576i
  • 4K x 2K
  • 3D


What is included with HDMI Power Inserter


  • 1 x HDMI Power Inserter
  • 1 x User Manual
  • 1 x 100-240vAC to +5vDC 2.6A Power Supply
  • 1 x 100-240VAC to 5V DC 2.6A Switch Mode Power Supply (Center Positive)

HDMI Power Inserter Images


HDMI Power Inserter - Full View
HDMI Power Inserter - Full View
HDMI Power Inserter - Front View
HDMI Power Inserter - Front View
HDMI Power Inserter - Back View
HDMI Power Inserter - Back View
HDMI Power Inserter - Connection Diagram
HDMI Power Inserter - Connection Diagram
HDMI Power Inserter - Power Supply 110v OR 240v
HDMI Power Inserter - Power Supply 110v OR 240v
