Convert PC and HDTV signals to HDMI Format using this model converter. Can accept a very wide range of resolutions from RGBHV and YPbPr sources to HDMI output.
PC/HD with Audio to HDMI Format Converter
This product has been replaced by :
View other products in this category
Convert PC and HDTV signals to HDMI Format using this model converter. Can accept a very wide range of resolutions from RGBHV and YPbPr sources to HDMI output.
Unit Dimensions:
9.0 x 7.0 x 3.0 cm
Shipping Weight:
0.51 kg
Location:
NSW, Australia
Item Type:
Condition:
New
Warranty :
12 Months
Certificates :
CE
Manual :
Features:
Enables you to connect computers with analog PC output or DVDs with YPbPr output to HDMI input of High Definition Plasma, LCD or DLP TV.
Selectable input format as PC/RGBHV or HD/YPbPr.
HDMI is compliant with HDMI 1.0
Supports up to 1600 x 1200 @ 60Hz for PC input and 1920 x 1080p @ 60Hz for HD input
Specifications:
Video Input: HD-15 (RGBHV/YPbPr).
Audio Input: Analog audio L.R.
HDMI is compliant with HDMI 1.0.
Operation frequency: up to 165 MHz.
Input/Output resolution:
PC: VGA@60, VGA@72, VGA@75, VGA@85, SVGA@60, SVGA@72, SVGA@75, SVGA@85, XGA@60, XGA@72, XGA@75, XGA@85, XGAi@87, SXGA@60, SXGA@75, SXGA@85, UXGA@60, 1152@70, 1152@75 and 1152@85.
HD: 480i@60, 576i@50, 480P@60, 576P@50, 720P@60, 720P@50, 1080i@60, 1080i@50, 1080P@60, 1080P@50, 1080P@30, 1080P@25, 1080P@24.
Using switch to select input format: HD/YPbPr or PC/RGBHV.
Dimension (WxHxD): 76 x 30 x 105mm.
Power Supply: DC 5V 2.6A Center positive.
Accepted Input PC VGA Resolutions:
640*480@60/72/75/85Hz
800*600@56/60/72/75/85Hz
1024*768@60/70/75/85Hz
1280*960@60/85Hz
1280*1024@60/75/85Hz
1600*1200@60Hz
1920*1600@60Hz
Accepted HD Component Resolutions:
720*480i@59/60Hz
720*480p@659/60Hz
720*576i@50Hz
720*576p@50Hz
1280*720p@50/59/60Hz
1920*1080i@50/59/60Hz
1920*1080p@50/59/60Hz
Power Supplies:
Multi-Voltage Power Supply : 100 - 240VAC to 5V DC 2.6A Switch Mode Power Supply - Center Positive
Connects From : Connects To :
VGA 15pin D-Sub (31K+)
Component - RGB & YCrCb/YPrPb (HDTV)
Converts From : Converts To :
VGA (640 x 480 @ 4:3)
SVGA (800 x 600 @ 4:3)
XGA (1024 x 768 @ 4:3)
SXGA (1280 x 1024 @ 5:4)
UXGA (1600 x 1200 @ 4:3)
HDTV 480p
HDTV 576p
HDTV 720p
HDTV 1080p
HDTV 1080i
HDTV 480i
HDTV 576i
RGB 31K
VGA (640 x 480 @ 4:3)
SVGA (800 x 600 @ 4:3)
XGA (1024 x 768 @ 4:3)
SXGA (1280 x 1024 @ 5:4)
UXGA (1600 x 1200 @ 4:3)
HDTV 480p
HDTV 576p
HDTV 720p
HDTV 1080p
HDTV 1080i
HDTV 480i
HDTV 576i
RGB 31K
1 x PC/HD with Audio to HDMI Format Converter
1 x VGA to 3 RCA
1 x Product Manual
1 x 100-240VAC to 5V DC 2.6A Switch Mode Power Supply (Center Positive)
PC/HD with Audio to HDMI Format Converter - Full View
PC/HD with Audio to HDMI Format Converter - Front View
PC/HD with Audio to HDMI Format Converter - Back View
PC/HD with Audio to HDMI Format Converter - VGA to 3 RCA
PC/HD with Audio to HDMI Format Converter - Power Supply 110v OR 240v
PC/HD with Audio to HDMI Format Converter - Full Kit
User Manual
