HDMI Matrix Selector - 4 input : 4 output

Superseded

This product has been replaced by :

HDMI v1.3 4 In 4 Out Matrix Box

300.00 USD

More Details

View other products in this category

HDMI Matrix Selector - 4 input : 2 output

270.00 USD

More Details

HDMI Matrix Selector 4 input : 4 output allows four HDMI sources to be directed to four HDMI display panels. Any HDMI source can be directed to one or all of the HDMI display panels. Ideal for use with HDMI devices such as DVD players, Set-top boxes, Game consoles and Multimedia centres.

Any four HDMI compliant devices can be connected to the HDMI Matrix Selector 4 input : 4 output for display to four High Definition TV's. You can use any combination of input to output, giving you up to 16 display scenarios. This is ideal for use in Professional and Academic fields or Private Home theatres.

All HDMI signals are re-timed, level compensated and phase/jitter adjusted for maximum quality video replay and display. The signal from each output of the HDMI Matrix Selector 4 input : 4 output can be run up to 25 meters. It can be cascaded for further distance requirements.

The HDMI Matrix Selector 4 input : 4 output can also be used by DVI devices. Simply connect your DVI source or display by using a HDMI/DVI converter cable.

Unit Dimensions:	44.0 x 17.5 x 4.5 cm	Shipping Weight:	2.55 kg
Location:	NSW, Australia	Item Type:	HDMI Video Matrix
Condition:	New	Warranty :	12 Months
Certificates :	CE, UL	Manual :	User Manual (263.49 KB)

HDMI Matrix Selector - 4 input : 4 output - Product Details

Practical Applications:

The HDMI Matrix Selector 4 input : 4 output is ideal for use in:

Lecture Halls and Auditoriums.
Educational Facilities such as Schools and Universities.
Shopping Malls and Large Retail Shops.
Sports Stadiums and Gymnasiums.
Recreational Resort and Accommodation Facilities.
Industrial Complexes.
Commercial Office Buildings.
Private Family Homes.

The HDMI Matrix Selector 4 input : 4 output is ideal for use by:

Professional Advertisers.
Lecture Professors, Public and Private Teachers.
Industrial Manufacturers.
Commercial Shop owners.
Resort and Motel/Hotel Managers
Sports Organisers.
Concert, Stage and Theatre groups.
Private Home Owners.

Features:

Stylish, slimline and durable silver/grey metal casing.
All push-buttons and connectors clearly labelled and accessible.
Hand held Remote Control.
RS-232 port for external PC control.
LED indicator for Power on/off.
LED indicators for source input and display output selected.
Supports High Definition Resolution input and output signals.
Compatible with all HDMI source and display devices.
DVI devices can be adapted for use.
Can be Cascaded for addition of more displays or to extend over long distance.
Up to 16 different input to output scenarios available.
Medium power consumption.

Specifications:

Input Connections: 4 x HDMI Type A (female)
Output Connections: 4 x HDMI Type A (female)
PC Resolutions: VGA, SVGA, XGA, SXGA, UXGA
HDTV Resolutions: 480i, 480p, 576i, 576p, 720p, 1080i, 1080p
Frequency Bandwidth: 1.65Gbps (Single link)
HDMI 1.2, HDCP 1.1, DVI 1.0 compliant
HDMI Input to Output Signal compensated for: Level, Timing, Phase error and Jitter
HDMI Output Signal: Efficient up to 25 meters before regeneration required.
Power: Universal Switch Mode Power Supply 100-240vAC to 5vDC 4.5A
Dimensions (cm's): 44.0(w) x 17.5(d) x 2.5(h)
Weight: 2.139Kg

Power Supplies:

Multi-Voltage Power Supply : 100 - 240VAC to 5V DC 4.5A Switch Mode Power Supply Centre Positive

Video and Audio Connection Type

Connects From :	Connects To :
HDMI (HDTV) VGA 9 pin D-sub	HDMI (HDTV)

Video and Audio Signal Conversion

Converts From :	Converts To :
VGA (640 x 480 @ 4:3) SVGA (800 x 600 @ 4:3) XGA (1024 x 768 @ 4:3) SXGA (1280 x 1024 @ 5:4) UXGA (1600 x 1200 @ 4:3) HDTV 480p HDTV 576p HDTV 720p HDTV 1080p HDTV 1080i HDTV 480i HDTV 576i	VGA (640 x 480 @ 4:3) SVGA (800 x 600 @ 4:3) XGA (1024 x 768 @ 4:3) SXGA (1280 x 1024 @ 5:4) UXGA (1600 x 1200 @ 4:3) HDTV 480p HDTV 576p HDTV 720p HDTV 1080p HDTV 1080i HDTV 480i HDTV 576i

What is included with HDMI Matrix Selector - 4 input : 4 output

1 x HDMI Matrix Selector 4 input : 4 output
1 x Remote Control
1 x Product Manual
1 x Switch Mode Power Supply 100-240vAC 1.5A to 30W 5vDC 6A Centre Positive

Additional Features

Remote Control

HDMI Matrix Selector - 4 input : 4 output Images

HDMI Matrix Selector - 4 input : 4 output - Full View

HDMI Matrix Selector - 4 input : 4 output - Front View

HDMI Matrix Selector - 4 input : 4 output - Back View

HDMI Matrix Selector - 4 input : 4 output - Side View

HDMI Matrix Selector - 4 input : 4 output - Top View

HDMI Matrix Selector - 4 input : 4 output - Remote

HDMI Matrix Selector - 4 input : 4 output - Power Supply 110v OR 240v

HDMI Matrix Selector - 4 input : 4 output - Full Kit
