HDMI Matrix Selector 4 input : 2 output allows four HDMI sources to be directed to two HDMI display panels. Any HDMI source can be directed to one or all of the HDMI display panels. Ideal for use with HDMI devices such as DVD players, Set-top boxes, Game consoles and Multimedia centres. Any four HDMI compliant devices can be connected to the HDMI Matrix Selector 4 input : 2 output for display to two High Definition TV's. You can use any combination of input to output, giving you up to 8 display scenarios. This is ideal for use in Professional and Academic fields or Private Home theatres. All HDMI signals are re-timed, level compensated and phase/jitter adjusted for maximum quality video replay and display. The signal from each output of the HDMI Matrix Selector 4 input : 2 output can be run up to 25 meters. It can be cascaded for further distance requirements. The HDMI Matrix Selector 4 input : 2 output can also be used by DVI devices. Simply connect your DVI source or display by using a HDMI/DVI converter cable.
HDMI Matrix Selector - 4 input : 2 output

HDMI Matrix Selector - 4 input : 2 output

  save 46%

Made In Taiwan

Product ID : 00508
Price : 280.80 USD (Change Currency)

RRP: 521.80 USD (less sale discount 241.00 USD )
Available : Stock


  Freight Quote On Sale
Contact Staff


HDMI Matrix Selector 4 input : 2 output allows four HDMI sources to be directed to two HDMI display panels. Any HDMI source can be directed to one or all of the HDMI display panels. Ideal for use with HDMI devices such as DVD players, Set-top boxes, Game consoles and Multimedia centres.

Any four HDMI compliant devices can be connected to the HDMI Matrix Selector 4 input : 2 output for display to two High Definition TV's. You can use any combination of input to output, giving you up to 8 display scenarios. This is ideal for use in Professional and Academic fields or Private Home theatres.

All HDMI signals are re-timed, level compensated and phase/jitter adjusted for maximum quality video replay and display. The signal from each output of the HDMI Matrix Selector 4 input : 2 output can be run up to 25 meters. It can be cascaded for further distance requirements.

The HDMI Matrix Selector 4 input : 2 output can also be used by DVI devices. Simply connect your DVI source or display by using a HDMI/DVI converter cable.


Unit Dimensions: 24.0 x 16.5 x 4.5 cm Shipping Weight: 1.76 kg
Location: NSW, Australia Item Type: HDMI Converters
Condition: New Warranty : 12 Months
Certificates : CE, UL Manual : PDF User Manual (250.73 KB)


HDMI Matrix Selector - 4 input : 2 output - Product Details


Practical Applications:

The HDMI Matrix Selector 4 input : 2 output is ideal for use in:

  • Lecture Halls and Auditoriums.
  • Educational Facilities such as Schools and Universities.
  • Shopping Malls and Large Retail Shops.
  • Sports Stadiums and Gymnasiums.
  • Recreational Resort and Accommodation Facilities.
  • Industrial Complexes.
  • Commercial Office Buildings.
  • Private Family Homes.

The HDMI Matrix Selector 4 input : 2 output is ideal for use by:

  • Professional Advertisers.
  • Lecture Professors, Public and Private Teachers.
  • Industrial Manufacturers.
  • Commercial Shop owners.
  • Resort and Motel/Hotel Managers
  • Sports Organisers.
  • Concert, Stage and Theatre groups.
  • Private Home Owners.

Features:

  • Stylish, slimline and durable silver/grey metal casing.
  • All push-buttons and connectors clearly labelled and accessible.
  • Hand held Remote Control.
  • RS-232 port for external PC control.
  • LED indicator for Power on/off.
  • LED indicators for source input and display output selected.
  • Supports High Definition Resolution input and output signals.
  • Compatible with all HDMI source and display devices.
  • DVI devices can be adapted for use.
  • Can be Cascaded for addition of more displays or to extend over long distance.
  • Up to 8 different input to output scenarios available.
  • Medium power consumption.

Specifications:

  • Input Connections: 4 x HDMI Type A (female)
  • Output Connections: 2 x HDMI Type A (female)
  • PC Resolutions: VGA, SVGA, XGA, SXGA, UXGA
  • HDTV Resolutions: 480i, 480p, 576i, 576p, 720p, 1080i, 1080p
  • Frequency Bandwidth: 1.65Gbps (Single link)
  • HDMI 1.2, HDCP 1.1, DVI 1.0 compliant
  • HDMI Input to Output Signal compensated for: Level, Timing, Phase error and Jitter
  • HDMI Output Signal: Efficient up to 25 meters before regeneration required.
  • Power: Universal Switch Mode Power Supply 100-240vAC to 5vDC 2.6A
  • Dimensions (cm's): 24.0(w) x 16.5(d) x 4.5(h)
  • Weight: 1.244Kg

Power Supplies:

  • Multi-Voltage Power Supply : 100-240V to 5V 3.2A Switch Mode Power Supply Center Positive


Video and Audio Connection Type


Connects From : Connects To :
  • HDMI (HDTV)
  • VGA 9 pin D-sub
  • HDMI (HDTV)


Video and Audio Signal Conversion


Converts From : Converts To :
  • VGA (640 x 480 @ 4:3)
  • SVGA (800 x 600 @ 4:3)
  • XGA (1024 x 768 @ 4:3)
  • SXGA (1280 x 1024 @ 5:4)
  • UXGA (1600 x 1200 @ 4:3)
  • HDTV 480p
  • HDTV 576p
  • HDTV 720p
  • HDTV 1080p
  • HDTV 1080i
  • HDTV 480i
  • HDTV 576i
  • VGA (640 x 480 @ 4:3)
  • SVGA (800 x 600 @ 4:3)
  • XGA (1024 x 768 @ 4:3)
  • SXGA (1280 x 1024 @ 5:4)
  • UXGA (1600 x 1200 @ 4:3)
  • HDTV 480p
  • HDTV 576p
  • HDTV 720p
  • HDTV 1080p
  • HDTV 1080i
  • HDTV 480i
  • HDTV 576i


What is included with HDMI Matrix Selector - 4 input : 2 output


  • 1 x HDMI Matrix Selector - 4 input : 2 output
  • 1 x Remote Control
  • 1 x Product Manual
  • 1 x Switchmode power supply 100 - 240V to 5V 3.2A (Center positive)

Additional Features


  • Remote Control

HDMI Matrix Selector - 4 input : 2 output Images


HDMI Matrix Selector - 4 input : 2 output - Full View
HDMI Matrix Selector - 4 input : 2 output - Full View
HDMI Matrix Selector - 4 input : 2 output - Front View
HDMI Matrix Selector - 4 input : 2 output - Front View
HDMI Matrix Selector - 4 input : 2 output - Back View
HDMI Matrix Selector - 4 input : 2 output - Back View
HDMI Matrix Selector - 4 input : 2 output - Side View
HDMI Matrix Selector - 4 input : 2 output - Side View
HDMI Matrix Selector - 4 input : 2 output - Top View
HDMI Matrix Selector - 4 input : 2 output - Top View
HDMI Matrix Selector - 4 input : 2 output - Remote
HDMI Matrix Selector - 4 input : 2 output - Remote
HDMI Matrix Selector - 4 input : 2 output - Power Supply 110v OR 240v
HDMI Matrix Selector - 4 input : 2 output - Power Supply 110v OR 240v
HDMI Matrix Selector - 4 input : 2 output - Full Kit
HDMI Matrix Selector - 4 input : 2 output - Full Kit
