  Home - HD-SD Distributor 1 input : 3 output w/Digital & Analog Audio Last Update: Sun 24th September 2023
HD-SD Distributor 1 input : 3 output (w/Digital & Analog Audio) is a versatile, high performance amplifier for distributing High Definition (HD) and Standard Definition (SD) Video signals. Analog and Digital audio is also supported. This splitter device has the ability to distribute three different Video formats of Composite (CV), Component (YPbPr/YCbCr) or RGB (Sync on Green and Separate Sync) to multiple CRT, LCD or Plasma displays. With application for Professional and Academic presentations or Home Theatre system owners, the HD-SD Distributor 1 input : 3 output (w/Digital & Analog Audio) is ideal for use by Installation Technicians and Private users. The HD-SD Distributor 1 input : 3 output (w/Digital & Analog Audio) works as a 1 input to 3 output distribution amplifier for HD/SD Component (YPbPr/YCbCr), HD RGsB (sync on green) or RGBHV (separate sync) and SD Composite Video sources. Supports outo 1080p / UXGA Input and Output. The Outputs enable connection to CRT, LCD and Plasma displays, with up to nine connections available for SD Composite Video and three for HD Component and RGB. Digital Co-axial and Analog Left/Right audio distribution is also supported, for individual distribution to each connected output display from each input source. Use Digital co-ax or Analog audio cable for easy connection to your displays speakers or any Hi-Fi System. Perfect for use by Professional, Academic and Private Presenters, Installers and Home Entertainment owners, the HD-SD Distributor 1 input : 3 output (w/Digital & Analog Audio) adds versatility with Video display and Audio reproduction for distribution growth potential in any application.
HD-SD Distributor 1 input : 3 output w/Digital & Analog Audio

HD-SD Distributor 1 input : 3 output w/Digital & Analog Audio

  save 15%

Made In Taiwan

Product ID : 00646
Price : 87.25 USD (Change Currency)

RRP: 102.60 USD (less sale discount 15.35 USD )
Available : Stock


  Freight Quote On Sale
Contact Staff


HD-SD Distributor 1 input : 3 output (w/Digital & Analog Audio) is a versatile, high performance amplifier for distributing High Definition (HD) and Standard Definition (SD) Video signals. Analog and Digital audio is also supported. This splitter device has the ability to distribute three different Video formats of Composite (CV), Component (YPbPr/YCbCr) or RGB (Sync on Green and Separate Sync) to multiple CRT, LCD or Plasma displays. With application for Professional and Academic presentations or Home Theatre system owners, the HD-SD Distributor 1 input : 3 output (w/Digital & Analog Audio) is ideal for use by Installation Technicians and Private users.

The HD-SD Distributor 1 input : 3 output (w/Digital & Analog Audio) works as a 1 input to 3 output distribution amplifier for HD/SD Component (YPbPr/YCbCr), HD RGsB (sync on green) or RGBHV (separate sync) and SD Composite Video sources. Supports outo 1080p / UXGA Input and Output. The Outputs enable connection to CRT, LCD and Plasma displays, with up to nine connections available for SD Composite Video and three for HD Component and RGB.

Digital Co-axial and Analog Left/Right audio distribution is also supported, for individual distribution to each connected output display from each input source. Use Digital co-ax or Analog audio cable for easy connection to your displays speakers or any Hi-Fi System.

Perfect for use by Professional, Academic and Private Presenters, Installers and Home Entertainment owners, the HD-SD Distributor 1 input : 3 output (w/Digital & Analog Audio) adds versatility with Video display and Audio reproduction for distribution growth potential in any application.


Unit Dimensions: 14.1 x 10.4 x 3.8 cm Shipping Weight: 0.89 kg
Location: NSW, Australia Item Type:
Condition: New Warranty : 12 Months
Certificates : CE Manual : PDF User Manual (562.12 KB)


HD-SD Distributor 1 input : 3 output w/Digital & Analog Audio - Product Details


Practical Applications:

The HD-SD Distributor 1-input : 3-output (w/Digital & Analog Audio) is ideal for use in:

  • Lecture Halls and Auditoriums.
  • Educational Facilities such as Schools and Universities.
  • Shopping Malls and Large Retail Shops.
  • Sports Stadiums and Gymnasiums.
  • Recreational Resort and Accommodation Facilities.
  • Industrial Complexes.
  • Commercial Office Buildings.
  • Private Family Homes.

The HD-SD Distributor 1-input : 3-output (w/Digital & Analog Audio) is ideal for use by:

  • Professional Advertisers.
  • Lecture Professors, Public and Private Teachers.
  • Industrial Manufacturers.
  • Commercial Shop owners.
  • Resort and Motel/Hotel Managers
  • Sports Organisers.
  • Concert, Stage and Theatre groups.
  • Private Home Owners.

Features:

  • PAL and NTSC working.
  • Input = Output.
  • Stylish, compact Black-Metal casing.
  • Easy to access and read Input/Output connectors.
  • Supports SD (Composite/YCbCr) and HD (YPbPr,RGsB,RGBHV) input Video signal.
  • Outputs 3 Component or RGB and 9 Composite Video signals.
  • High Bandwidth performance.
  • Ideal for Presentation and Home Theatre applications.
  • Auto detection of Input for Outputs..
  • Supports upto 1080p / UXGA resolution Input/Output.

Specifications:

  • Video Input: Component-YPbPr/YCbCr x 1; RGB-RGsB/RGBHV x 1; Composite x 3 (1v p-p @ 75ohm)
  • Video Outputs: Component-YPbPr/YCbCr x 3; RGB-RGsB/RGBHV x 3; Composite 3 x 3 (9)
  • Audio Inputs: Digital Coaxial S/PDIF x 1; Analog Left/Right S/PDIF x 1.
  • Audio Outputs: Digital Coaxial S/PDIF x 3; Analog Left/Right S/PDIF x 3.
  • Analog Audio Input / output: Audio 2Vrms max 47k ohm.
  • Synchronisation: Horizontal/Vertical 5V p-p max. H=10KHz-100Khz, V=20Hz-200Hz.
  • Bandwidth: 480Mhz @ -3dB.
  • Differential Gain: 0.05%
  • Differential Phase: 0.05 degree
  • Power: Switch Mode 100-240vAC to 5vDC 1A
  • Dimensions (cm's): 14.1(l) x 10.4(w) x 3.8(h)
  • Weight(grams): 0.426

Please Note:


  • Power supply available in 110V or 220V (please mention the type you require when ordering)
  • Power plug adapter available for most countries (please mention the type you require when ordering)

Power Supplies:

  • Multi-Voltage Power Supply : 100-240VAC to 5V DC 1A Switch Mode Power Supply Centre Positive - Aus Plug


Video and Audio Connection Type


Connects From : Connects To :
  • Composite - RCA / AV (TV)
  • RGB Separate Sync - RGBHV
  • RGB Sync on Green - RGsB
  • Component - Y/Cb/Cr
  • Component - Y/Pb/Pr
  • Composite - RCA / AV (TV)
  • RGB Separate Sync - RGBHV
  • RGB Sync on Green - RGsB
  • Component - Y/Cb/Cr
  • Component - Y/Pb/Pr


Video and Audio Signal Conversion


Converts From : Converts To :
  • VGA (640 x 480 @ 4:3)
  • SVGA (800 x 600 @ 4:3)
  • XGA (1024 x 768 @ 4:3)
  • SXGA (1280 x 1024 @ 5:4)
  • UXGA (1600 x 1200 @ 4:3)
  • HDTV 480p
  • HDTV 576p
  • HDTV 720p
  • HDTV 1080p
  • HDTV 1080i
  • HDTV 480i
  • HDTV 576i
  • VGA (640 x 480 @ 4:3)
  • SVGA (800 x 600 @ 4:3)
  • XGA (1024 x 768 @ 4:3)
  • SXGA (1280 x 1024 @ 5:4)
  • UXGA (1600 x 1200 @ 4:3)
  • HDTV 480p
  • HDTV 576p
  • HDTV 720p
  • HDTV 1080p
  • HDTV 1080i
  • HDTV 480i
  • HDTV 576i


What is included with HD-SD Distributor 1 input : 3 output w/Digital & Analog Audio


  • 1 x HD-SD Distributor 1input : 3output w/Digital & Analog Audio
  • 1 x Composite - RCA Cable (Male to Male)
  • 1 x Stereo RCAs (Male to Male)
  • 1 x Component Cable
  • 1 x Product Manual
  • 1 x Switch Mode Power Supply 100-240vAC to 5vDC 1A (Centre Positive)

HD-SD Distributor 1 input : 3 output w/Digital & Analog Audio Images


HD-SD Distributor 1 input : 3 output w/Digital & Analog Audio - Full View
HD-SD Distributor 1 input : 3 output w/Digital & Analog Audio - Full View
HD-SD Distributor 1 input : 3 output w/Digital & Analog Audio - Front View
HD-SD Distributor 1 input : 3 output w/Digital & Analog Audio - Front View
HD-SD Distributor 1 input : 3 output w/Digital & Analog Audio - Back View
HD-SD Distributor 1 input : 3 output w/Digital & Analog Audio - Back View
HD-SD Distributor 1 input : 3 output w/Digital & Analog Audio - Side View
HD-SD Distributor 1 input : 3 output w/Digital & Analog Audio - Side View
HD-SD Distributor 1 input : 3 output w/Digital & Analog Audio - Top View
HD-SD Distributor 1 input : 3 output w/Digital & Analog Audio - Top View
HD-SD Distributor 1 input : 3 output w/Digital & Analog Audio - Composite - RCA Cable (Male to Male)
HD-SD Distributor 1 input : 3 output w/Digital & Analog Audio - Composite - RCA Cable (Male to Male)
HD-SD Distributor 1 input : 3 output w/Digital & Analog Audio - Stereo RCAs (Male to Male)
HD-SD Distributor 1 input : 3 output w/Digital & Analog Audio - Stereo RCAs (Male to Male)
HD-SD Distributor 1 input : 3 output w/Digital & Analog Audio - Component Cable
HD-SD Distributor 1 input : 3 output w/Digital & Analog Audio - Component Cable
HD-SD Distributor 1 input : 3 output w/Digital & Analog Audio - Power Supply 110v OR 240v
HD-SD Distributor 1 input : 3 output w/Digital & Analog Audio - Power Supply 110v OR 240v
HD-SD Distributor 1 input : 3 output w/Digital & Analog Audio - Full Kit
HD-SD Distributor 1 input : 3 output w/Digital & Analog Audio - Full Kit
