The Manufacture of This "Wide Viewing Angle" Product Has Been Halted Temporarily. We Will Reactivate This Product When Production is Restarted.

The ID#492 "Normal Viewing Angle" is Now Available For Purchase:

http://www.converters.tv/products/vga_to_vga/492.html

We Apologise For Any Inconvenience

12.1 Inch CGA EGA VGA to SVGA LCD Panel with Wide Viewing Angle feature. It will accept a wide range of RGB inputs including CGA, EGA and VGA for display up to SVGA resolution. Ideal as an update for replacement of older superceded CRT and LCD monitors, this unit is made for CNC Industrial and Commercial applications.

The VESA plug & play system allows the monitor to automatically adjust itself to match the frequency of the user's connected input device. The frequency range for horizontal is 15KHz to 47KHz and for vertical is 48Hz to 75Hz.

For users connecting this model to a computer it uses Display Data Channel (DDC) to send Extended Display Identification Data (EDID) to the computer, so the computer system can be set to monitor auto adjust. This model of monitor will auto adjust itself to enhance the picture quality of the device connected to it. As well as self test function which will check to ensure all functions of the monitor are working properly.

To ensure maximum compatibility with input signals, it has more timing data and resolutions than any other LCD panel. The current resolution and timing information for the connected input device is displayed in the top bar of the OSD menu. Image positioning for Horizontal and Vertical and an all important crush feature allows you to shrink the size of the image both horizontal and vertically to make the image fit on the screen.

The monitor has a Super MVA - Wide Viewing Angle. As well as a OSD menu and a self test function. The easy to understand and clear graphics of the OSD (on screen display) menu make it simple to make any changes necessary.

Power Supply for the 12.1 Inch CGA EGA VGA to SVGA LCD Panel can be 110VAC or 240VAC, regulated via a Universal Switch Mode Power Adapter to 12VDC 4A. (Please specify power cord required when ordering.)


Unit Dimensions: 28.4 x 21.8 x 5.0 cm Shipping Weight: 4.52 kg
Location: NSW, Australia Item Type: CRT + LCD Monitors
Condition: New Warranty : 12 Months
Certificates : CE, CTick, UL Manual : PDF User Manual (267.37 KB)


12.1 Inch CGA EGA VGA to SVGA LCD Panel (Wide Viewing Angle) - Product Details


Features:

  • Compact, durable metal casing.
  • Easy to adapt to CNC machines.
  • Function button control board can be placed in convenient position for access.
  • OSD menu for full display image management.
  • Input Modes: CGA/EGA/VGA to SVGA.
  • Resolution Range: 640 x 200 (CGA) to 800 x 600 (SVGA).
  • Auto Power Saver for when no signal is detected at inputs.
  • Fast Image display response time for when signal is detected at inputs.

Specifications:

  • Screen Size: 12.1 inch TFT
  • Aspect Ratio: 4:3
  • Weight: 1.61kg
  • Dimensions (cm's): 28.4(w) x 21.8(d) x 3.8(h) Note:5.0(h) w/controller attached
  • Input Mode: CGA/EGA/VGA/SVGA
  • Max Resolution: 800 x 600 (SVGA)
  • RGB CGA/EGA Input connections: 10 pin in-line plug.
  • RGB VGA Input connection: 15 pin D-sub socket.
  • Windows Compatibility: 98, 2000, XP, Vista, Windows 7. Other Operating Systems also suitable.
  • PC Interface: Analog Interface
  • Input Signal: 0.7Vpp Analog 75ohm
  • Sync: TTL level Separate, Composite
  • Sync Polarity: Positive (+ve) & Negative (-ve)
  • Scan Frequency Horizontal: 15~47KHZ
  • Scan Frequency Vertical 48~75Hz
  • Screen Horizontal Size: 248.0mm
  • Screen Vertical Size: 187.0mm
  • Colours: 262K Colors
  • 5 Function Keys: Power, Menu/Auto, Up, Down, Source/Esc
  • OSD Funcions: Contrast, Brightness, Sharpness, Phase, Clocking, Colour Temperature, Colour RGB, Auto Colour, Image Alignment (H and V), Screen test, OSD Timer, Language and Input source.
  • Power 100~240V 47/63Hz via 12VDC 4A adapter
  • Power Consumption: 25 Watts Max
  • Power management: Vesa-Dpms 25 watts Power down mode ≤3 Watts
  • Bandwidth: 30MHz Dot Clock
  • Pixel Pitch(mm): 0.3075 x 0.3075
  • Backlight: CCFL x 2
  • Cell Type: SMVA
  • Contrast Ratio: 1000:1 Typ
  • Brightness: 450cd/m squared
  • Viewing Angle: H=178 degrees, V=178 degrees
  • Response Time: 25ms(on + off)
  • Operating Temperature: 0 degrees ~ 40 Degrees
  • Humidity - 10~85%

CGA + EGA + VGA + SVGA Input Specifications


  • CGA - 15.4kHz x 58.8Hz (Resolution - 640x198 @ 58)
  • CGA - 15.1kHz x 57.6Hz (Resolution - 640x215 @ 57)
  • CGA - 15.7kHz x 60Hz (Resolution - 640x215 @ 60)
  • CGA - 16.0kHz x 61Hz (Resolution - 640x215 @ 61)
  • CGA - 16.3kHz x 62Hz (Resolution - 640x215 @ 62)
  • CGA - 16.6kHz x 63.4Hz (Resolution - 640x215 @ 63.4)
  • CGA - 16.80kHz x 64Hz (Resolution - 640x215 @ 64)
  • CGA - 15.6kHz x 50.3Hz (Resolution - 640x265 @ 50)
  • CGA - 18.4kHz x 50Hz (Resolution - 640x350 @ 50)
  • EGA - 21.8kHz x 58.9Hz (Resolution - 640x350 @58)
  • EGA - 24.4kHz x 59.5Hz (Resolution - 645x355 @59)
  • EGA - 23.5kHz x 52Hz (Resolution - 720x378 @52)
  • EGA - 26.4kHz x 57.4Hz (Resolution - 720x400 @57)
  • VGA - 31.469kHz x 70.087Hz (Resolution - 640x400 @ 70)
  • VGA - 31.469kHz x 59.940Hz (Resolution - 640x480 @ 60)
  • VGA - 37.861kHz x 72.809Hz (Resolution - 640x480 @ 72)
  • VGA - 37.500kHz x 75.000Hz (Resolution - 640x480 @ 75)
  • SVGA - 35.156kHz x 56.250Hz (Resolution - 800x600 @ 56)
  • SVGA - 37.879kHz x 60.317Hz (Resolution - 800x600 @ 60)
  • SVGA - 48.077kHz x 72.188Hz (Resolution - 800x600 @ 72)
  • SVGA - 46.875kHz x 75.000Hz (Resolution - 800x600 @ 75)

Power Supplies:

  • Multi-Voltage Power Supply : Power Cable 250V 10A


Video and Audio Signal Conversion


Converts From : Converts To :
  • VGA (640 x 480 @ 4:3)
  • CGA (15k)
  • EGA (24K)
  • SVGA (800 x 600 @ 4:3)
  • RGB (15K Video)
  • RGB Sync on Green RGsB
  • CGA Compatible 15K Video Source
  • RGB Combined Sync - RGBH+V
  • RGB Separate Sync - RGBHV
  • RGB 31K
  • CGA Combined Sync (15khz)
  • CGA Separate Sync (15khz)
  • CGA Sync on Green (15khz)
  • VGA (640 x 480 @ 4:3)
  • SVGA (800 x 600 @ 4:3)


What is included with 12.1 Inch CGA EGA VGA to SVGA LCD Panel (Wide Viewing Angle)


  • 1 x CGA, EGA, VGA to SVGA LCD Panel with Wide Viewing Angle
  • 1 x VGA Cable
  • 1 x 10 Pin RGB cable
  • 1 x Product Manual
  • 1 x Power Cable 250V 10A

12.1 Inch CGA EGA VGA to SVGA LCD Panel (Wide Viewing Angle) Images


12.1 Inch CGA EGA VGA to SVGA LCD Panel (Wide Viewing Angle) - Full View
12.1 Inch CGA EGA VGA to SVGA LCD Panel (Wide Viewing Angle) - Full View
12.1 Inch CGA EGA VGA to SVGA LCD Panel (Wide Viewing Angle) - Front View
12.1 Inch CGA EGA VGA to SVGA LCD Panel (Wide Viewing Angle) - Front View
12.1 Inch CGA EGA VGA to SVGA LCD Panel (Wide Viewing Angle) - Back View
12.1 Inch CGA EGA VGA to SVGA LCD Panel (Wide Viewing Angle) - Back View
12.1 Inch CGA EGA VGA to SVGA LCD Panel (Wide Viewing Angle) - Bottom View
12.1 Inch CGA EGA VGA to SVGA LCD Panel (Wide Viewing Angle) - Bottom View
12.1 Inch CGA EGA VGA to SVGA LCD Panel (Wide Viewing Angle) - VGA Cable
12.1 Inch CGA EGA VGA to SVGA LCD Panel (Wide Viewing Angle) - VGA Cable
12.1 Inch CGA EGA VGA to SVGA LCD Panel (Wide Viewing Angle) - Power Adapter
12.1 Inch CGA EGA VGA to SVGA LCD Panel (Wide Viewing Angle) - Power Adapter
12.1 Inch CGA EGA VGA to SVGA LCD Panel (Wide Viewing Angle) - 10 Pin RGB cable
12.1 Inch CGA EGA VGA to SVGA LCD Panel (Wide Viewing Angle) - 10 Pin RGB cable
12.1 Inch CGA EGA VGA to SVGA LCD Panel (Wide Viewing Angle) - Power Supply 110v OR 240v
12.1 Inch CGA EGA VGA to SVGA LCD Panel (Wide Viewing Angle) - Power Supply 110v OR 240v
12.1 Inch CGA EGA VGA to SVGA LCD Panel (Wide Viewing Angle) - Full Kit
12.1 Inch CGA EGA VGA to SVGA LCD Panel (Wide Viewing Angle) - Full Kit
