1 x 2 DVI Splitter

save 35%

Product ID :

15327

Price :

100.45 USD (Change Currency)

RRP: 154.10 USD

(less sale discount 53.65 USD )

Available :

Stock

Freight Quote On Sale Contact Staff

1 x 2 DVI Splitter DA distribution amplifier is designed to split a DVI signal to two DVI monitors without signal loss or degredation. Connect your DVD player, PC or Game Console to display to two separate screens. Supports PC resolutions VGA up to WUXGA and HD resolutions 480p up to 1080i/p (not 480i/576i). Ideal for shop signage displays and video distribution between and around large rooms or buildings.

The DVI Splitter series are high performance, HDCP compliant DVI distribution amplifiers. It allows one DVI signal source to be split to two identical buffered outputs for connecting DVI displays simultaneously. These models can be used to transfer HDMI™ signals by using an HDMI to DVI adaptor or cable. Each of the buffered outputs can be run up to 15 meters and can be cascaded. EDID supported (records EDID of o/p 1, sent to source)

Unit Dimensions:	12.5 x 10.2 x 3.0 cm	Shipping Weight:	0.56 kg
Location:	NSW, Australia	Item Type:
Condition:	New	Warranty :	12 Months
Certificates :	CE, CTick, UL	Manual :	User Manual (175.71 KB)

1 x 2 DVI Splitter - Product Details

Features:

HDMI and DVI 1.0 compliant
Compatible with HDMI signal (with adaptor cable)
Supports a wide range of PC and HDTV resolutions from VGA to WUXGA and 480p to 1080p
Can be cascaded up to 3 layers
The device will read and record the EDID of output 1 and then send it to the source device

Specifications:

Input Port: 1×DVI
Output Ports: 2, 4 or 8×DVI
Audio Sampling Rate: Up to 192 kHz (with DVI to HDMI Adaptor)
Power Supply: 100-240vAC to +5v 2.6A DC (US/EU standards, CE/FCC/UL certified)
ESD Protection Human body model: ±8 kV (air-gap discharge), ±6 kV (contact discharge)
Dimensions: 102 mm (W)×125 mm (D)×30 mm (H)
Weight: 280 g
Chassis Material: Metal
Silkscreen Color: Black
Operating Temperature: 0 ˚C ~ 40 ˚C / 32 ˚F ~ 104 ˚F
Storage Temperature: −20 ˚C~60 ˚C / −4 ˚F~140 ˚F
Relative Humidity: 20 ~ 90 % RH (non-condensing)
Power Consumption: 3.5 W

Power Supplies:

Multi-Voltage Power Supply : 100 - 240VAC to 5V DC 2.6A Switch Mode Power Supply - Center Positive

Video and Audio Connection Type

Connects From :	Connects To :
DVI - D (HDTV) HDMI (HDTV)	DVI - D (HDTV) HDMI (HDTV)

Video and Audio Signal Conversion

Converts From :	Converts To :
VGA (640 x 480 @ 4:3) SVGA (800 x 600 @ 4:3) XGA (1024 x 768 @ 4:3) SXGA (1280 x 1024 @ 5:4) UXGA (1600 x 1200 @ 4:3) HDTV 480p HDTV 576p HDTV 720p HDTV 1080p HDTV 1080i WUXGA (1920 x 1080 @ 16:10) HDTV 480i HDTV 576i WXGA (1280 X 768 @ 5:3)	VGA (640 x 480 @ 4:3) SVGA (800 x 600 @ 4:3) XGA (1024 x 768 @ 4:3) SXGA (1280 x 1024 @ 5:4) UXGA (1600 x 1200 @ 4:3) HDTV 480p HDTV 576p HDTV 720p HDTV 1080p HDTV 1080i WUXGA (1920 x 1080 @ 16:10) HDTV 480i HDTV 576i WXGA (1280 X 768 @ 5:3)

What is included with 1 x 2 DVI Splitter

1 x 1 x 2 DVI Splitter
1 x User Manual
1 x Product Manual
1 x 100-240VAC to 5V DC 2.6A Switch Mode Power Supply (Center Positive)

1 x 2 DVI Splitter Images

1 x 2 DVI Splitter - Full View

1 x 2 DVI Splitter - Front View

1 x 2 DVI Splitter - Back View

1 x 2 DVI Splitter - Power Supply 110v OR 240v
