VGA PC to PAL-NTSC Video Converter

Superseded

This product has been replaced by :

PC VGA WUXGA to Video Converter

84.00 USD

More Details

View other products in this category

250V 10A Universal Travel Power Plug Adapter South Africa Model

3.00 USD

More Details

This VGA PC to PAL-NTSC Video Converter allows the image from your computer to be displayed on your TV. The unit is designed to convert a variety of computer images to interlaced NTSC or PAL video for viewing on your TV, and is capable of handling high resolution PC input up to UXGA (1600x1200).

The VGA PC to PAL-NTSC Video Converter is capable of handling resolutions from 640x480 up to 1600x1200. The unit is remarkably easy to set up and use. It includes one PC input port where you can connect your PC's VGA cable, while the output of the VGA PC to PAL-NTSC Video Converter is selectable between Composite Video or S-Video for connection to your monitor. The VGA PC to PAL-NTSC Video Converter also allows you to switch between NTSC or PAL, depending on your monitor system.

It is ideal for home theatre and entertainment use, as well as applications that include video conferences, business presentations, lectures and advertising purposes.

The VGA PC to PAL-NTSC Video Converter has built in 'retain last settings' function. This means that, even if power is totally removed from the converter, when power is re-connected, the converter will automatically start with the parameters last used.

Unit Dimensions:	11.5 x 6.5 x 2.3 cm	Shipping Weight:	0.32 kg
Location:	NSW, Australia	Item Type:
Condition:	New	Warranty :	12 Months
Certificates :	CE, UL	Manual :	User Manual (166.24 KB)

VGA PC to PAL-NTSC Video Converter - Product Details

Practical Applications:

The PAL-NTSC-SECAM Video to PAL-NTSC Video Converter is ideal for use in:

Lecture Halls and Auditoriums.
Educational Facilities such as Schools and Universities.
Shopping Malls and Large Retail Shops.
Sports Stadiums and Gymnasiums.
Recreational Resort and Accommodation Facilities.
Industrial Complexes.
Commercial Office Buildings.
Private Family Homes.

The PAL-NTSC-SECAM Video to PAL-NTSC Video Converter is ideal for use by:

Professional Advertisers.
Lecture Professors, Public and Private Teachers.
Industrial Manufacturers.
Commercial Shop owners.
Resort and Motel/Hotel Managers
Sports Organisers.
Concert, Stage and Theatre groups.
Private Home Owners.

Features:

Lightweight, durable, silver/grey hard plastic casing.
Easy to instal and operate.
Switch selectable Power on/off.
LED indicator for Power on/off.
Easy scale-down from PC resolutions VGA to UXGA to Composite & S-Video output.
All connectors and switches clearly labelled and accessible.
Switch selectable NTSC or PAL output.
Switch selectable Underscan or Overscan selection.
Low power consumption.

Specifications:

PC input resolutions: VGA (640 x 480) upto UXGA (1600 x 1200).
Video outputs: Composite (CV) and S-Video (SV)
PC input connection: 15 pin HD D-con.
Composite Video output connector: 1 x RCA socket 1v p-p 75 ohm.
S-Video output connector: 1 x Mini-Din 1v p-p 75 ohm.
Standards & Certifications: US, EU, CE/FCC/UL.
Universal Switch Mode Power Supply 100-240vAC to 5vDC 1A
Dimensions (cm's): 11.5(w) x 6.5(d) x 2.3(h)
Weight: 100 grams

Power Supplies:

Multi-Voltage Power Supply : 100-240VAC to 5V DC 1A Switch Mode Power Supply Centre Positive - Aus Plug

Video and Audio Connection Type

Connects From :	Connects To :
VGA 15pin D-Sub (31K+)	Composite - RCA / AV (TV) S-Video (TV)

Video and Audio Signal Conversion

Converts From :	Converts To :
VGA (640 x 480 @ 4:3) SVGA (800 x 600 @ 4:3) XGA (1024 x 768 @ 4:3) SXGA (1280 x 1024 @ 5:4) UXGA (1600 x 1200 @ 4:3)	PAL B NTSC M - NTSC 3.58 NTSC N - NTSC 4.43 PAL D PAL N PAL G PAL H PAL I PAL K PAL M

What is included with VGA PC to PAL-NTSC Video Converter

1 x VGA PC to PAL-NTSC Video Converter
1 x Composite - RCA Cable (Male to Male)
1 x Product Manual
1 x 100-240VAC to 5V DC 1A Switch Mode Power Supply (Centre Positive) (Aus Plug)

VGA PC to PAL-NTSC Video Converter Images

VGA PC to PAL-NTSC Video Converter - Full View

VGA PC to PAL-NTSC Video Converter - Front View

VGA PC to PAL-NTSC Video Converter - Back View

VGA PC to PAL-NTSC Video Converter - Left View

VGA PC to PAL-NTSC Video Converter - Right View

VGA PC to PAL-NTSC Video Converter - Top View

VGA PC to PAL-NTSC Video Converter - Power Supply 110v OR 240v

VGA PC to PAL-NTSC Video Converter - Full Kit
