2.4GHz wireless CMOS camera & receiver with USB Video Capture

Features:

• Supports RCA Video IN, S-Video IN and stereo phone jack Audio IN.
• Built-in microphone.
• Four channels available for best quality selection.
• View or record the image on TV, VCR/VCD/DVD player or computer with video capture function.
• When you connect a RCA cable to the Video IN of receiver, it will replace and disconnect the remote input video signal.
• It is the best for application on Entertainment/ Attendance/ Surveillance and market on DIY, SOHO and security.
• Supports Windows 98/Me/2000.

Specifications:

Transmitter:

• 2.4~2.483 GHz frequency range: CH1=2410 MHz, CH2=2430 MHz, CH3=2450 MHz, CH4=2470 MHz.
• Frequency deviation: ± 100KHz (10 degrees~50 degrees).
• 1/3" CMOS video camera with built-in 2.4GHz wireless AV sender.
• 300 TV lines; 300,000 pixels; 3 Lux.
• Demodulation method: FM.
• RF Output power: Vcc=3.3V, LOAD=50, 10 dBm.
• Horizontal Scanning Frequency: NTSC-15.734KHz, PAL-15.625 KHz.
• Vertical Scanning Frequency: NTSC-59.94 Hz, PAL- 50.00Hz.
• S/N ratio: With AGC OFF 46dB.
• Dipole antenna (85mm) provides optimal video and audio reception.
• Supports NTSC or PAL video systems.
• Built-in microphone.
• The wireless colour CMOS video camera pivots 360 degrees on mounting stand for optimal installation.
• Power Supply: DC 6V 800mA Center positive.
• Power Consumption: 0.5W MAX.
• Operating temperature: 10 degrees- 50 degrees.
• Dimensions: W100 x D80 x H60 mm.

Receiver:

• ISM Band: 2400Mhz~2483Mhz Audio/Video on four selectable channels: CH1=2410 MHz, CH2=2430MHz, CH3=2450MHz, CH4=2470MHz.
• Interface: USB V1.1.
• Antenna Mode: Dipole, which provides optimal video and audio reception.
• Video output: Composite Video 1Vp-p.
• Audio Output: RCA-L, RCA_R (1Vrms).
• Antenna Port: 50 Ohm PCB Track.
• RF Receiver current consumption: under 450mA. (Typical).
• RF Receiver Sensitivity: -80dbm. (Minimum).
• High Speed compression supports real-time image output.
• Supports the following video formats and frame rate compression: 640x480-9~15fps, 352x288-25~30fps, 320x240-30fps, 176x144-30fps, 160x120-30fps.
• Video/Audio Source- INT (from RF CMOS camera)/EXT(Video IN: Audio IN:S-Video).
• Capture key: Snap-shot key/Software capture.
• Video Frame: 320x240 (30 frames)/640x480 (12 frames).
• TWAIN compatible hardware CAPTURE.
• Power source: DC 6V 800mA Center positive.
• Operation temperature: 10 degrees~50 degrees.
• Dimensions: D125 x W90 x H30 mm.

Please Note:

• Power supply available in 110V or 220V (please mention the type you require when ordering).
• Power plug adapter available for most countries (please mention the type you require when ordering).

Power Supplies:

• 240 Volt Model : 240V Australian Power Supply

• 1 x 2.4GHz wireless CMOS camera & receiver with USB Video Capture
• 1 x Composite - RCA Cable (Male to Male)
• 1 x S-Video - Super Video Cable (Male to Male)
• 1 x Line Jack Cable
• 1 x Video and Stereo AV Cable
• 1 x Software
• 1 x Mounting Kit
• 2 x Power Supply: DC 6V 800mA Center positive
