Composite S-Video to HDMI 1080p Scaler Format Converter

save 36%

Superseded

The Composite S-Video to HDMI 1080p Scaler Format Converter is designed to upscale a SD (standard definition) Analog video/audio source to a HD (high definition) Digital HDMI video/audio output signal. The Digital output signal can be selected from a wide-range of scaled HDTV and PC resolutions, up to 1080p and WUXGA. The Composite S-Video to HDMI 1080p Scaler Format Converter can also convert a Digital or Analog audio signal and then simultaneously outputs via HDMI, Optical and 3.5mm Mini-jack (L/R audio) connections. This unit has a comprehensive OSD menu that allows the user to make picture adjustments to optimize the image quality.

Unit Dimensions:	18.7 x 10.2 x 2.5 cm	Shipping Weight:	0.87 kg
Location:	NSW, Australia	Item Type:
Condition:	New	Warranty :	12 Months
Certificates :	CE, CTick, UL	Manual :	User Manual (222.98 KB)

Composite S-Video to HDMI 1080p Scaler Format Converter - Product Details

Features:

HDMI, HDCP and DVI compliant
Supports video standards NTSC, NTSC4, PAL, PAL-M, PAL-N and SECAM
Supports upscaling of resolutions from PC VGA to WUXGA@60Hz, or HD 480p, 576p, 720p@50/60Hz, 1080i/p@50/60Hz
Supports 50/60Hz frame rate conversion
Auto detects the display settings of the connected monitor and outputs the correct resolution and refresh rate, when the output option 'NATIVE' is selected
Supports 3D motion video adaptive, 3D de-interlacing and 3:2/2:2 pull down detection and recovery
Provides adjustment of contrast, brightness, hue, saturation, sharpness, RGB (color tone) level and aspect ratio
Supports OSD selection of analog or digital audio inputs, with simultaneous analog and digital audio output via HDMI and TOSlink Optical digital audio and analog 3.5mm mini-jack connections

Specifications:

Bandwidth: 225MHz / 6.75Gbps
Inputs: 1 x S-video plug (1 x 4-pin DIN), 1 x RCA (1 x Composite), 2 x RCA (1 x Stereo L/R), 1 x TOSlink (1 x Optical 2 CH LPCM), 1 x USB Type A (1 x Propriety Data)
Outputs: 1 x HDMI (1 x Uncompressed AV and Data), 2 x RCA (1 x Stereo L/R), 1 x TOSlink (1 x Optical 2 CH LPCM)
HDMI Output Resolutions: PC VGA to WUXGA@60Hz, or HD 480p, 576p, 720p@50/60Hz, 1080i/p@50/60Hz
HDMI and Optical Audio Sampling Rates: up to 48kHz
Power Supply: 100-240vAC to +5vDC 2.6A (US/EU standards; CE/Fcc/UL certified)
Power Consumption (watts): 4.1w
Dimensions (cm): 18.7 (d) x 10.2 (w) x 2.5 (h) (w/jacks)
Net Weight (grams): 395g
Chassis: Black Aluminum
Opertaing Temperature: 0c ~ 40c / 32f ~ 104f
Relative Humidity: 20% ~ 90% RH (non-condensing)
ESD Protection: Human body model: ±8kV (contact); ±6kV (air gap)

Power Supplies:

Multi-Voltage Power Supply : 100 - 240VAC to 5V DC 2.6A Switch Mode Power Supply - Center Positive

Video and Audio Connection Type

Connects From :	Connects To :
Composite - RCA / AV (TV) S-Video (TV) Analog Stereo L/R Jacks SPDIF Digital Audio Interface	HDMI (HDTV) 3.5mm Headphone Jack SPDIF Digital Audio Interface

Video and Audio Signal Conversion

Converts From :	Converts To :
PAL B NTSC M - NTSC 3.58 NTSC N - NTSC 4.43 PAL N PAL M	HDTV 480p HDTV 576p HDTV 720p HDTV 1080p HDTV 1080i RGB 31K

What is included with Composite S-Video to HDMI 1080p Scaler Format Converter

1 x Composite S-Video to HDMI 1080p Scaler Format Converter
1 x User Manual
1 x 100-240vAC to +5vDC 2.6A
1 x User Manual
1 x 100-240vAC to +5vDC 2.6A
1 x Product Manual
1 x Composite - RCA Cable (Male to Male)
1 x Stereo RCAs (Male to Male)
1 x 100-240VAC to 5V DC 2.6A Switch Mode Power Supply (Center Positive)

Composite S-Video to HDMI 1080p Scaler Format Converter Images

Composite S-Video to HDMI 1080p Scaler Format Converter - Full View

Composite S-Video to HDMI 1080p Scaler Format Converter - Front View

Composite S-Video to HDMI 1080p Scaler Format Converter - Back View

Composite S-Video to HDMI 1080p Scaler Format Converter - Connection Diagram

Composite S-Video to HDMI 1080p Scaler Format Converter - Composite - RCA Cable (Male to Male)

Composite S-Video to HDMI 1080p Scaler Format Converter - Stereo RCAs (Male to Male)

Composite S-Video to HDMI 1080p Scaler Format Converter - Power Supply 110v OR 240v
