UHD 4K 6G Audio Extractor

save 13%

Product ID :

15477

Price :

166.30 USD (Change Currency)

RRP: 190.10 USD

(less sale discount 23.80 USD )

Available :

Stock

Freight Quote On Sale Contact Staff

This UHD 4K 6G Audio Extractor extracts up to 8 channels of LPCM audio from an HDMI source and allows the user to convert high quality lossless HDMI audio into multi-channel analog signals, for use with powered speakers or non-HDMI AV receivers.

The UHD 4K 6G Audio Extractor supports 8 channel analog Bitstream extraction via RCA sockets, with an additional digital optical S/PDIF output.

Both the input and output HDMI ports support up to 4K@60Hz (YUV4:4:4, 8-bit) resolution, capable of supporting high quality audio and video performance.

The UHD 4K 6G Audio Extractor supports pass-through of HD bitstream audio formats, as well as standard bitstream formats and 7.1 LPCM. Audio sampling rate is up to 192 kHz.

In-built EDID management allows the UHD 4K 6G Audio Extractor to make selection from multiple EDIDs and with the use of optional PC software, to edit, upload and download the EDID files.

Unit Dimensions:	23.4 x 11.6 x 2.5 cm	Shipping Weight:	1.05 kg
Location:	NSW, Australia	Item Type:
Condition:	New	Warranty :	12 Months
Certificates :	CE, CTick, UL	Manual :	User Manual (290.53 KB)

UHD 4K 6G Audio Extractor - Product Details

Features:

HDMI input and output with 18Gbps / 600MHz 4K UHD support
DVI 1.0 compliant with the use of an HDMI-DVI adaptor
HDCP 1.4 and 2.2 compliant
Supports HD resolutions up to 3940x2160@60Hz (YUV 4:4:4, 8-bit) & 4096x2160@60Hz (YUV 4:4:4, 8-bit)
Supports 48-bit Deep Color up to 1080p@60Hz
2 slots for user-created EDIDs, and EDID bypass support
Supports pass-through of LPCM 7.1, bitstream and HD bitstream audio formats over HDMI
Audio extraction to 8 channel analog output and optical S/PDIF output
Supports HDMI audio sampling rates up to 192 kHz
Supports S/PDIF audio sampling rates up to 192 kHz
Provides EDID management with EDID bypass and 2 user modifiable EDIDs
PC based EDID management tool support
Supports RS-232 style control via a Virtual COM port over USB

Specifications:

Video Bandwidth: 600MHz / 18Gbps
Input Ports: 1 x HDMI; 1 x mini-USB (service & control only)
Output Port: 1 x HDMI; 1 x Optical S/PDIF (Digital Audio; 8 x Analog RCA
HDMI Audio Sampling Rate: up to 192kHz
Optical Audio Sampling Rate: up to 192kHz
HDMI Cable I/O Distance: 10m 1080p@60Hz, 12-bit; 15m 1080p@60Hz, 8-bit
HDMI Audio Format: LPCM 2.0 / 5.1 / 7.1, Bitstream, HD Bitstream
Optical Audio Format: LPCM 2.0, Bitstream
Analog Audio Format: 8 Channel
Power Supply: 100-240vAC to +5vDC 2.6A (US/EU standards; CE/FCC/ UL certified)
Power Consumption (watts): 4.7w
Dimensions (cm's): 21.35 (w) x 10.8 (d) x 2.5 (h) (case only); 23.4 (w) x 11.6 (d) x 2.5 (h) (all included)
Weight (grams): 626g
Chassis: Black Metal
Operating Temperature: 0c ~ 40c / 32f ~ 104f
Relative Humidity: 20% ~ 90% RH (non-condensing)
ESD Protection: Human Body Model: +/-12kV (air-gap discharge); +/-8kV (contact discharge)

Power Supplies:

Multi-Voltage Power Supply : 100-240VAC to 5V DC 2.6A Switch Mode Power Supply (Center Positive) Screw Connector

Video and Audio Connection Type

Connects From :	Connects To :
HDMI (HDTV) USB (Service)	HDMI (HDTV) Optical TOSlink S/PDIF Analog Stereo L/R Jacks

Video and Audio Signal Conversion

Converts From :	Converts To :
HDTV 480p HDTV 576p HDTV 720p HDTV 1080p HDTV 1080i HDTV 480i HDTV 576i 4K x 2K 3D	HDTV 480p HDTV 576p HDTV 720p HDTV 1080p HDTV 1080i HDTV 480i HDTV 576i Optical S/PDIF Analog Stereo L/R Audio 4K x 2K 3D

What is included with UHD 4K 6G Audio Extractor

1 x UHD 4K 6G Audio Extractor
1 x Product Manual
1 x 100-240VAC to 5V DC 2.6A Switch Mode Power Supply (Center Positive) Screw Connector

UHD 4K 6G Audio Extractor Images

UHD 4K 6G Audio Extractor - Full View

UHD 4K 6G Audio Extractor - Front View

UHD 4K 6G Audio Extractor - Back View

UHD 4K 6G Audio Extractor - Power Supply 110v OR 240v
