The HDMI v1.4 4 In 1 Out Switcher - Wall Mountable is a high performance four HDMI input and one HDMI output switcher with digital audio inputs and outputs. It supports an HDCP repeater function and fast switching between any of the four HDMI input ports. The HDMI v1.4 4 In 1 Out Switcher (Wall Mountable) supports all 3D TV formats in addition to all HDTV HDMI v1.4 formats up to 1080p 12-bit Deep Color. A remote control provides easy access to select the source video signal required for viewing. Installation is an easy and pain free process. All inputs and outputs are clearly marked and accessible. The wall mountable design is for hidden installation, and the device is DVI compatible.
HDMI v1.4 4 In 1 Out Switcher - Wall Mountable

HDMI v1.4 4 In 1 Out Switcher - Wall Mountable

  save 37%

Made In Taiwan

Product ID : 00860
Price : 164.50 USD (Change Currency)

RRP: 262.60 USD (less sale discount 98.10 USD )
Available : Stock


  Freight Quote On Sale
Contact Staff


The HDMI v1.4 4 In 1 Out Switcher - Wall Mountable is a high performance four HDMI input and one HDMI output switcher with digital audio inputs and outputs.

It supports an HDCP repeater function and fast switching between any of the four HDMI input ports.

The HDMI v1.4 4 In 1 Out Switcher (Wall Mountable) supports all 3D TV formats in addition to all HDTV HDMI v1.4 formats up to 1080p 12-bit Deep Color.

A remote control provides easy access to select the source video signal required for viewing. Installation is an easy and pain free process.

All inputs and outputs are clearly marked and accessible. The wall mountable design is for hidden installation, and the device is DVI compatible.


Unit Dimensions: 18.5 x 9.3 x 3.0 cm Shipping Weight: 0.72 kg
Location: NSW, Australia Item Type: HDMI Converters
Condition: New Warranty : 12 Months
Certificates : CE, CTick, UL Manual : PDF User Manual (661.68 KB)


HDMI v1.4 4 In 1 Out Switcher - Wall Mountable - Product Details


Features:

  • Supports multiplexed HDMI 4 input and 1 output
  • Display 3D content
  • Display HDMI v1.4 content
  • HDMI 1.4, HDCP 1.4 and CEC1.4 compliant
  • HDMI 1.4 support: Audio Return Channel (ARC), 3D TV support, CEC1.4
  • Fast switching on all HDMI input ports
  • Character and icon based On-Screen Display (OSD): System information for Software version, Sink EDID, Source infoframe, HDMI input Audio & Audio Return selection
  • HDCP repeater support
  • Deep Color support 36/30/24-bit, 1080p@60Hz
  • HDMI cable distance tested with 1080p 8/12 bits resolution, the input & output distance can run up to 10 &15 meters
  • Audio support: HDMI 1.4 compatible audio interface, Dedicated, flexible audio input/output port, Dolby TrueHD, DTS-HD Master Audio 7.1CH, Full audio input and output support

Specifications:

  • Frequency Bandwidth: 2.25Gbps
  • Input Ports: 4 x HDMI Female ports
  • Output port: 1 x HDMI Female port
  • HDMI Output Resolution: 480i ~1080p 50/60, 1080p24, VGA~WUXGA
  • HDMI Audio Output: PCM2, 5.1, 7.1CH, Dolby 5.1, DTS5.1, DD+, D-TrueHD, DTS-HD
  • HDMI Cable In: 1080p 8-bit (10M), 12-bit (10M)
  • HDMI Cable Out: 1080p 8-bit (15M), 12-bit (15M)
  • Coaxial Audio Output: PCM2CH
  • Power Supply: 5V/1A DC (US/EU standards, CE/FCC/UL certified)
  • ESD Protection: Human Body Model: ± 8kV (air-gap discharge), ± 4kV (contact discharge)
  • Dimensions (mm): 100 (W) x 70 (D) x 20 (H)
  • Weight (g): 90
  • Chassis Material: Plastic
  • Silkscreen Colour: White
  • Power Consumption: 4W
  • Operating Temperature: 0˚C ~ 40˚C / 32˚F ~ 104˚F
  • Storage Temperature: -20˚C ~ 60˚C / -4˚F ~ 140˚F
  • Relative Humidity: 20~60% RH (non-condensing)

Power Supplies:

  • Multi-Voltage Power Supply : 100-240V 0.2A 50/60Hz to 5V DC 1000mA 6W Max Power Supply Center Positive


Video and Audio Connection Type


Connects From : Connects To :
  • DVI - D (HDTV)
  • HDMI (HDTV)
  • DVI - D (HDTV)
  • HDMI (HDTV)


Video and Audio Signal Conversion


Converts From : Converts To :
  • HDTV 480p
  • HDTV 576p
  • HDTV 720p
  • HDTV 1080p
  • HDTV 1080i
  • HDTV 480i
  • HDTV 576i
  • HDTV 480p
  • HDTV 576p
  • HDTV 720p
  • HDTV 1080p
  • HDTV 1080i
  • HDTV 480i
  • HDTV 576i


What is included with HDMI v1.4 4 In 1 Out Switcher - Wall Mountable


  • 1 x HDMI 4 by 1 Switcher - Wall Mount
  • 1 x Product Manual
  • 1 x Infrared sensor
  • 1 x 100-240V 0.2A 50/60Hz to 5V DC 1000mA 6W Max Power Supply (Center Positive)

Additional Features


  • Remote Control

HDMI v1.4 4 In 1 Out Switcher - Wall Mountable Images


HDMI v1.4 4 In 1 Out Switcher - Wall Mountable - Full View
HDMI v1.4 4 In 1 Out Switcher - Wall Mountable - Full View
HDMI v1.4 4 In 1 Out Switcher - Wall Mountable - Front View
HDMI v1.4 4 In 1 Out Switcher - Wall Mountable - Front View
HDMI v1.4 4 In 1 Out Switcher - Wall Mountable - Right View
HDMI v1.4 4 In 1 Out Switcher - Wall Mountable - Right View
HDMI v1.4 4 In 1 Out Switcher - Wall Mountable - Left View
HDMI v1.4 4 In 1 Out Switcher - Wall Mountable - Left View
HDMI v1.4 4 In 1 Out Switcher - Wall Mountable - Top View
HDMI v1.4 4 In 1 Out Switcher - Wall Mountable - Top View
HDMI v1.4 4 In 1 Out Switcher - Wall Mountable - Infrared sensor
HDMI v1.4 4 In 1 Out Switcher - Wall Mountable - Infrared sensor
HDMI v1.4 4 In 1 Out Switcher - Wall Mountable - Remote
HDMI v1.4 4 In 1 Out Switcher - Wall Mountable - Remote
HDMI v1.4 4 In 1 Out Switcher - Wall Mountable - Power Supply 110v OR 240v
HDMI v1.4 4 In 1 Out Switcher - Wall Mountable - Power Supply 110v OR 240v
HDMI v1.4 4 In 1 Out Switcher - Wall Mountable - Full Kit
HDMI v1.4 4 In 1 Out Switcher - Wall Mountable - Full Kit
