  Home - HDMI to HDMI Scaler Box Last Update: Sun 24th September 2023
The HDMI to HDMI Scaler Box is designed to scale an HDMI video signal, outputting in a wide range of HDTV or PC resolutions up to 1080p or WUXGA. Additionally, this HDMI to HDMI Scaler Box can convert a digital or analog audio signal and outputs the signal to standard HDMI, Optical TOSlink and 3.5mm line-jack connectors. The HDMI to HDMI Scaler Box has a comprehensive OSD menu that allows you to easily select from a variety of output resolutions and to make adjustments to optimize the image quality.
HDMI to HDMI Scaler Box

HDMI to HDMI Scaler Box

  save 3%

Made In Taiwan

Superseded



The HDMI to HDMI Scaler Box is designed to scale an HDMI video signal, outputting in a wide range of HDTV or PC resolutions up to 1080p or WUXGA.

Additionally, this HDMI to HDMI Scaler Box can convert a digital or analog audio signal and outputs the signal to standard HDMI, Optical TOSlink and 3.5mm line-jack connectors.

The HDMI to HDMI Scaler Box has a comprehensive OSD menu that allows you to easily select from a variety of output resolutions and to make adjustments to optimize the image quality.


Unit Dimensions: 10.2 x 15.6 x 2.5 cm Shipping Weight: 0.80 kg
Location: NSW, Australia Item Type:
Condition: New Warranty : 12 Months
Certificates : CE, CTick, UL Manual : PDF User Manual (167.21 KB)


HDMI to HDMI Scaler Box - Product Details


Features:

  • HDMI, HDCP and DVI compliant
  • Supports full range of PC resolutions from VGA ~ WUXGA(RB) and HD resolutions 480i/p ~ 1080i/p
  • Auto detect Factory setting of connected display and output the correct resolution for that display
  • Provides output picture ajustment for contrast, brightness, hue, saturation, sharpness, RGB (colour tone) level and aspect ratio size.
  • Supports 50Hz to 60Hz and 60Hz to 50Hz video format conversion (PAL/NTSC)
  • Supports 3-D motion video adaptive, 3-D de-interlacing and 3:2/2:2 pull-down detection and recovery
  • Supports stereo LPCM analog/digital audio input and simultaneous stereo LPCM analog/digital audio output to HDMI, Optical TOSlink and 3.5mm line-jack

Specifications:

  • Video Bandwidth: 225MHz / 6.75Gbps
  • Input Ports: 1 x HDMI; 1 x 3.5mm line-jack; 1 x Optical TOSlink; 1 x USB (Service Only)
  • Output Ports: 1 x HDMI; 1 x Optical TOSlink; 1 x 3.5mm line-jack
  • HDMI output resolutions: VGA~WUXGA(RB) and 480i/p~1080i/p
  • Audio Input/Output: LPCM 2CH analog and digital
  • Audio Sampling Rate: up to 48kHz / TOSlink & HDMI
  • Power Supply: 100-240vAC to +5vDC 2.6A (US/EU standards; CE/FCC/UL certified)
  • Power Consumption (watts): 5.5w
  • Dimensions (cm's): 10.2(w) x 14.7(d) x 2.5(h) w/out jacks; 10.2(w) x 15.58(d) x 2.5(h) w/jacks
  • Weight (grams): 338g
  • Chassis: Black Aluminium
  • Operating Temperature: 0c ~ 40c / 32f ~ 104f
  • Relative Humidity: 20%~90% RH (non-condensing)
  • ESD Protection: Human Body Model: ±8kV (air-gap); ±4kV (contact)


Video and Audio Connection Type


Connects From : Connects To :
  • HDMI (HDTV)
  • Optical TOSlink S/PDIF
  • 3.5mm Headphone Jack
  • USB (Service)
  • HDMI (HDTV)
  • Optical TOSlink S/PDIF
  • 3.5mm Headphone Jack


Video and Audio Signal Conversion


Converts From : Converts To :
  • HDTV 480p
  • HDTV 576p
  • HDTV 720p
  • HDTV 1080p
  • HDTV 1080i
  • HDTV 480i
  • HDTV 576i
  • Optical S/PDIF
  • Analog Stereo L/R Audio
  • HDTV 480p
  • HDTV 576p
  • HDTV 720p
  • HDTV 1080p
  • HDTV 1080i
  • HDTV 480i
  • HDTV 576i
  • Optical S/PDIF
  • Analog Stereo L/R Audio


What is included with HDMI to HDMI Scaler Box


  • 1 x HDMI to HDMI Scaler Box
  • 1 x Line Jack to Stereo AV Cable
  • 1 x Product Manual
  • 1 x 100-240VAC to 5V DC 2.6A Switch Mode Power Supply (Center Positive)

HDMI to HDMI Scaler Box Images


HDMI to HDMI Scaler Box - Full View
HDMI to HDMI Scaler Box - Full View
HDMI to HDMI Scaler Box - Front View
HDMI to HDMI Scaler Box - Front View
HDMI to HDMI Scaler Box - Back View
HDMI to HDMI Scaler Box - Back View
HDMI to HDMI Scaler Box - Connection Diagram
HDMI to HDMI Scaler Box - Connection Diagram
HDMI to HDMI Scaler Box - Line Jack to Stereo AV Cable
HDMI to HDMI Scaler Box - Line Jack to Stereo AV Cable
HDMI to HDMI Scaler Box - Power Supply 110v OR 240v
HDMI to HDMI Scaler Box - Power Supply 110v OR 240v
