  Home - HDTV Converters - HDTV To HDTV Converters - 4K UHD+ HDMI over IP Transceiver with USB Extension Last Update: Mon 29th May 2023
The 4K UHD+ HDMI over IP Transceiver with USB Extension is designed for high-quality, IP routable, AV extension with minimum latency. Every Transceiver can be configured to function as either a Transmitter or a Receiver, enhancing the flexibility of any installation. By using a sophisticated ultra-light compression scheme (lossless for most content) the 4K UHD+ HDMI over IP Transceiver with USB Extension is a great solution for extending 4K HDMI audio/video streams and data. Advanced HDMI content such as HDR (High Dynamic Range), 10-bit color and multi-channel HD Bitstream audio can be transmitted in pass-through mode. The use of high quality 10-Gigabit Ethernet ports and Cat.6A cable allows for point-to-point transmission of the video signal up to a distance of 100 metres. Multiple control and data signals may also be transmitted along with the audio and video, including IR, RS-232, USB 2.0 and Ethernet. When combined with the optional control center or control software, the functionality of the 4K UHD+ HDMI over IP Transceiver with USB Extension expands exponentially. Multiple Transceivers may be combined with one or more 10-Gigabit Ethernet switches and then used together to form a distributed video matrix, a multi-viewer system or a video wall system, adding to flexibility in large event installations. The integrated USB hub of each 4K UHD+ HDMI over IP Transceiver with USB Extension can be configured to be in USB Host Mode, or Device Mode and can function as a simple point to point KVM extension, freely routed between any two endpoints. It can also be configured into a special “Simultaneous” mode, allowing up to 7 Host Mode Transceivers to extend their USB ports to a single Device Mode Transceiver. This type of USB KVM routing flexibility enables a wide range of multi-user, control room and on-demand installation scenarios. The 4K UHD+ HDMI over IP Transceiver with USB Extension may be powered directly by PoE (Power over Ethernet) when connected via Cat.6A cable to a 10-Gigabit Ethernet switch that provides the PoE (802.3at) allowing for great flexibility in installation location. The built-in EDID and HDCP management functionality enables the unit to fit into every situation. Basic configuration of the unit can be achieved via front panel buttons with an On-Screen Display (OSD). Advanced control requires optional control center, or control software, and a LAN connection. - Recommended Accessories: ID#15534 or ID#15624 - AV over IP Master Controller
4K UHD+ HDMI over IP Transceiver with USB Extension

4K UHD+ HDMI over IP Transceiver with USB Extension

  save 17%

Made In Taiwan

Superseded



The 4K UHD+ HDMI over IP Transceiver with USB Extension is designed for high-quality, IP routable, AV extension with minimum latency. Every Transceiver can be configured to function as either a Transmitter or a Receiver, enhancing the flexibility of any installation.

By using a sophisticated ultra-light compression scheme (lossless for most content) the 4K UHD+ HDMI over IP Transceiver with USB Extension is a great solution for extending 4K HDMI audio/video streams and data. Advanced HDMI content such as HDR (High Dynamic Range), 10-bit color and multi-channel HD Bitstream audio can be transmitted in pass-through mode.

The use of high quality 10-Gigabit Ethernet ports and Cat.6A cable allows for point-to-point transmission of the video signal up to a distance of 100 metres. Multiple control and data signals may also be transmitted along with the audio and video, including IR, RS-232, USB 2.0 and Ethernet.

When combined with the optional control center or control software, the functionality of the 4K UHD+ HDMI over IP Transceiver with USB Extension expands exponentially. Multiple Transceivers may be combined with one or more 10-Gigabit Ethernet switches and then used together to form a distributed video matrix, a multi-viewer system or a video wall system, adding to flexibility in large event installations.

The integrated USB hub of each 4K UHD+ HDMI over IP Transceiver with USB Extension can be configured to be in USB Host Mode, or Device Mode and can function as a simple point to point KVM extension, freely routed between any two endpoints. It can also be configured into a special “Simultaneous” mode, allowing up to 7 Host Mode Transceivers to extend their USB ports to a single Device Mode Transceiver.

This type of USB KVM routing flexibility enables a wide range of multi-user, control room and on-demand installation scenarios.

The 4K UHD+ HDMI over IP Transceiver with USB Extension may be powered directly by PoE (Power over Ethernet) when connected via Cat.6A cable to a 10-Gigabit Ethernet switch that provides the PoE (802.3at) allowing for great flexibility in installation location.

The built-in EDID and HDCP management functionality enables the unit to fit into every situation. Basic configuration of the unit can be achieved via front panel buttons with an On-Screen Display (OSD). Advanced control requires optional control center, or control software, and a LAN connection.

  • Recommended Accessories: ID#15534 or ID#15624 - AV over IP Master Controller




Unit Dimensions: 23.2 x 11.7 x 2.5 cm Shipping Weight: 0.90 kg
Location: NSW, Australia Item Type:
Condition: New Warranty : 12 Months
Certificates : CE, CTick, UL


4K UHD+ HDMI over IP Transceiver with USB Extension - Product Details


Features:

  • HDMI 2.0 and DVI 1.0 compatible
  • HDCP 2.2 and HDCP 1.x compliant
  • Can be configured to function as either a Transmitter or a Receiver
  • 1 HDMI input
  • 1 HDMI output (Functions as local monitor output in Transmitter Mode)
  • 1 analog stereo jack (Functions as an input in Transmitter Mode or an output in Receiver Mode)
  • 2 USB Type-A ports and 1 USB Mini-B port
  • IP switchable with minimum latency (requires optional control center/ software)
  • Ultra-light compression, lossless for most content
  • Extension up to 100m in point-to-point mode (w/ Cat.6A cable)
  • Independent breakaway A/V matrix switching (requires optional control center/software)
  • Video wall generation (requires optional control center/software)
  • Multi-view compositing (requires optional control center/software)
  • Supports pass-through of 10/12-bit HDR sources (Point-to-point and Genlock modes only)
  • Supports pass-through of audio formats including LPCM (up to 8 channels), Bitstream and HD Bitstream from HDMI sources
  • Analog stereo audio extension, insertion and extraction (insertion and extraction requires optional control center/software)
  • Bi-directional IR, RS-232, USB 2.0, and Ethernet extension
  • Supports a special Simultaneous Mode for USB extension allowing a host connected to a single Transceiver to connect to up to 7 Transceivers with USB devices connected (mass storage devices are not supported in this mode)
  • Unit can be powered directly by PoE when connected to a 10-Gigabit Ethernet (10GbE) switch that provides PoE (802.3at)
  • Signal transmission interfaces with 10-Gigabit Ethernet switches via a single Cat.6A cable
  • Basic configuration via front panel buttons with an On-Screen Display (OSD)
  • Supports the use of an external control center or control software to provide expanded functionality (Contact your authorized dealer for more information)

Specifications:

  • Input Port: 1 x HDMI (Type-A)
  • Output Port: 1 x HDMI (Type-A)
  • Bi-directional Port: 1 x 10GbE LAN (RJ-45)
  • Pass-through Ports: 1 x Unbalanced Stereo (3.5mm); 1 x IR Extender (3.5mm); 1 x IR Blaster (3.5mm); 1 x RS-232 (3-pin Terminal Block); 1 x Ethernet (RJ-45); 2 x USB (Type-A)
  • Pass-through/Service Port: 1 x USB (Mini-B)
  • Video:
  • Input Signal Types: HDMI 2.0 w/ 4K60, HDR10
  • Output Signal Types: HDMI 2.0 w/ 4K60, HDR10
  • Input Color Depth: 8-bit, 10-bit, 12-bit, 16-bit
  • Output Color Depth: 8-bit, 10-bit, 12-bit, 16-bit
  • HDCP Compliance: 1.x, 2.2
  • Maximum Input and Output:
  • HDMI Resolution: 4096*2160p@60; 2560*1600p@60RB
  • Bandwidth: 18Gbps
  • Streaming Resolution: 4096*2160p@60; 2560*1600p@60RB 10Gbps
  • Bandwidth: 10Gbps
  • Please Note: Bandwidth values represent the maximum supported by the interface. Processable signal maximums may be lower.
  • Audio:
  • Digital Formats: HDMI 8CH LPCM, Bitstream, HD Bitstream
  • Analog Formats: Unbalanced 2 Channel
  • Line Level:
  • Frequency Response: < ±0.5dB (20Hz to 20kHz)
  • THD: < 0.02% (20Hz to 20kHz)
  • S/N Ratio: > 80dB (1kHz with 0dBFS)
  • Crosstalk: < −80dB (10kHz, Vin=0dBFS)
  • Power Supply: +12vDC 3A (Locking)
  • Power Consumption (watts): 30w (Full load)
  • Chassis: Black Metal
  • Dimensions (cm's): 23.15 (w) × 10.8 (d) × 2.5 (h) [Case Only]; 23.15 (w) × 11.67 (d) × 2.5 (h) [All Inclusive]teel)
  • Weight (grams): 552g


Video and Audio Connection Type


Connects From : Connects To :
  • HDMI (HDTV)
  • USB (PC) Type A Device Ports
  • RJ-45 Ethernet
  • LAN
  • IR Extender (Rx)
  • RS-232 Terminal Block
  • Mini USB - Control
  • HDMI (HDTV)
  • IR Blaster (Tx)


Video and Audio Signal Conversion


Converts From : Converts To :
  • HDTV 480p
  • HDTV 576p
  • HDTV 720p
  • HDTV 1080p
  • HDTV 1080i
  • HDTV 480i
  • HDTV 576i
  • 4K x 2K
  • HDTV 480p
  • HDTV 576p
  • HDTV 720p
  • HDTV 1080p
  • HDTV 1080i
  • HDTV 480i
  • HDTV 576i
  • 4K x 2K


What is included with 4K UHD+ HDMI over IP Transceiver with USB Extension


  • 1 x 4K UHD+ HDMI over IP Transceiver with USB Extension

4K UHD+ HDMI over IP Transceiver with USB Extension Images


4K UHD+ HDMI over IP Transceiver with USB Extension - ID#15628 Full View.png
4K UHD+ HDMI over IP Transceiver with USB Extension - ID#15628 Full View.png
4K UHD+ HDMI over IP Transceiver with USB Extension - ID#15628 Front View.png
4K UHD+ HDMI over IP Transceiver with USB Extension - ID#15628 Front View.png
4K UHD+ HDMI over IP Transceiver with USB Extension - ID#15628 Back View.png
4K UHD+ HDMI over IP Transceiver with USB Extension - ID#15628 Back View.png
