1 Input 4 Output 4K2K HDMI 6G Splitter

save 15%

Product ID :

15409

Price :

177.65 USD (Change Currency)

RRP: 209.05 USD

(less sale discount 31.40 USD )

Available :

Stock

Freight Quote On Sale Contact Staff

New generation 1 Input 4 Output 4K2K HDMI 6G Splitter is an advanced solution for splitting and distributing a single HDMI signal simultaneously to 2, 4, 8 or 10 HDMI outputs. Apart from providing support for UHD video, up to 4K2K@60Hz (YUV444) resolution, it also supports audio pass-through of high resolution digital formats such as LPCM7.1CH, Dolby TrueHD, Dolby Digital Plus, DTS-HD Master Audio and Dolby Atmos with sampling rates up to 192kHz.

This new generation 1 Input 4 Output 4K2K HDMI 6G Splitter has front panel display LED's to indicate input and output operating status. It has switch selectable EDID control, so when in 'TV' mode it stores and uses data from the first connected HDTV and in 'STD' mode it scans each connected display @1080p/LPCM 2CH. A system reset button uses CEC protocol to ensure the connected HDTV automatically defaults to and remains on the HDMI input connected to the Splitter.

Applications:

Advertising displays
Commercial displays
Lecture Halls
Show Rooms
Private Home Theatres

Unit Dimensions:	23.2 x 11.8 x 2.5 cm	Shipping Weight:	1.02 kg
Location:	NSW, Australia	Item Type:
Condition:	New	Warranty :	12 Months
Certificates :	CE, CTick, UL	Manual :	User Manual (219.11 KB)

1 Input 4 Output 4K2K HDMI 6G Splitter - Product Details

Features:

HDMI (with 6G audio/video support), HDCP 2.2 and DVI compliant (note: does not support 'Deep Color'/color space - YCbCr 422/444)
1 HDMI input and 4 HDMI outputs
Supports System Reset function (CEC active source command)
Simultaneous display of a single Ultra High-Definition source on up to 4 UHDTV displays
3D passthrough with compatible 3D source and 3D TV
Supports UHDTV resolutions up to 4K2K: 3840×2160@24/25/30/50/60Hz & 4096×2160@24/25/30/60Hz
Supports passthrough of high definition audio: LPCM 2/5.1/7.1CH, Dolby Digital 2/5.1CH, DTS 2/5.1CH, Dolby TrueHD, DTS-HD Master Audio & Dolby Atmos
HDCP 2.2 and HDCP1.4 compliant
HDMI input supports 'Standard' mode and 'TV' mode EDID settings

Specifications:

Video Bandwidth: 600Mhz / 18 Gbps
Input Ports: 1 x HDMI, 1 x mini USB (Service Only)
Output Ports: 4 x HDMI
HDMI Resolutions: VGA ~ WUXGA (RB), 408p/i ~ 1080p/i@24/50/60Hz; 4K@24/25/30Hz, 4K@50/60Hz(YUV444)
HDMI Cable Distance: 10m@1080p 8-bit, 5m@1080p12-bit, 5m@4K
Power Supply: 100-240vAC to +5vDC 2.6A (US/EU standards; CE/FCC/UL certified)
Power Consumption (watts): 3.42w
Dimensions (cm's): 23.2 (w) x 11.8 (d) x 2.5 (h) (jacks)
Weight (grams): 620g
Chassis: Metal / Black
Operating Temperature: 0c ~ 40c / 32f ~ 104f
ESD Protection: Human Body Model: ±8kV (air-gap); ±4kV (contact)
Relative Humidity: 20% ~ 90% RH (non-condensing)

Video and Audio Connection Type

Connects From :	Connects To :
HDMI (HDTV) Mini USB - Power Only	HDMI (HDTV)

Video and Audio Signal Conversion

Converts From :	Converts To :
HDTV 480p HDTV 576p HDTV 720p HDTV 1080p HDTV 1080i HDTV 480i HDTV 576i 4K x 2K	HDTV 480p HDTV 576p HDTV 720p HDTV 1080p HDTV 1080i HDTV 480i HDTV 576i 4K x 2K

What is included with 1 Input 4 Output 4K2K HDMI 6G Splitter

1 x 1 Input 4 Output 4K2K HDMI 6G Splitter
1 x 100-240vAC to +5vDC 2.6A Power Supply
1 x Product Manual

1 Input 4 Output 4K2K HDMI 6G Splitter Images

1 Input 4 Output 4K2K HDMI 6G Splitter - Full View

1 Input 4 Output 4K2K HDMI 6G Splitter - Front View

1 Input 4 Output 4K2K HDMI 6G Splitter - Back View
