New 1 In 2 Out UHD 4K2K Splitter Scaler with Audio De-Embedding is designed to upscale a HD 1080p signal to a UHD 6G 4K2K signal, or downscale a UHD 6G 4K2K signal to a HD 1080p signal, with synchronized digital and analog audio output.
The 1 In 2 Out UHD 4K2K Splitter Scaler with Audio De-Embedding has a simple and convenient design with a comprehensive OSD menu that allows the User to control the available configurations and settings for each individual output. It also functions as a 1 x 2 DA to pass unscaled video to both outputs. It can display UHD 4K2K (YUV 4:4:4) video to both HDMI outputs simultaneously, or it can have each output display a different resolution (one showing 1080p, the other showing 4K2K).
Additionally, the 1 In 2 Out UHD 4K2K Splitter Scaler with Audio De-Embedding can generate test patterns with assigned resolutions allowing for easy, on-site display testing. This UHD Scaler is a fantastic tool for both professional Systems Installers and Home Theatre enthusiasts.
New 1 In 2 Out UHD 4K2K Splitter Scaler with Audio De-Embedding is designed to upscale a HD 1080p signal to a UHD 6G 4K2K signal, or downscale a UHD 6G 4K2K signal to a HD 1080p signal, with synchronized digital and analog audio output.
The 1 In 2 Out UHD 4K2K Splitter Scaler with Audio De-Embedding has a simple and convenient design with a comprehensive OSD menu that allows the User to control the available configurations and settings for each individual output. It also functions as a 1 x 2 DA to pass unscaled video to both outputs. It can display UHD 4K2K (YUV 4:4:4) video to both HDMI outputs simultaneously, or it can have each output display a different resolution (one showing 1080p, the other showing 4K2K).
Additionally, the 1 In 2 Out UHD 4K2K Splitter Scaler with Audio De-Embedding can generate test patterns with assigned resolutions allowing for easy, on-site display testing. This UHD Scaler is a fantastic tool for both professional Systems Installers and Home Theatre enthusiasts.
1 In 2 Out UHD 4K2K Splitter Scaler - Product Details
Features:
HDMI input and outputs with 6G (4K@60Hz YUV 4:4:4) support
HDCP 2.2 compliant
Supports HDCP 2.2 to HDCP 1.4 conversion
Supports HDMI signal bypass on both outputs or upscale a HD 1080p signal to UHD 4K2K on output B and downscale an UHD 4K2K signal to a HD 1080p on output A (upscale/downscale)
Supports 4K2K@50/60Hz (YUV 4:4:4) to 4K2K@50/60Hz (YUV 4:2:0) conversion
Supports auto pattern generation with selected HD or UHD resolutions for on-site display testing
Supports HDMI input of 1 x 6G and HDMI outputs of 2 x 6G
Includes EDID management functions
Supports High-Dynamic-Range (HDR) images
Supports HDR conversion from 4K2K@24/25/30Hz(444/422) 10bit or 12bit to 4096 *2160@24/25/30Hz 8bit fix
Supports data rates up to 6 Gbps (600MHz) and Deep Color up to 1080p 48bit
Supports pass-through of HD audio formats of LPCM 2 /5.1 / 7.1CH, Dolby Digital 2~5.1CH, DTS 2~5.1CH, Dolby Digital Plus, Dolby TrueHD, Dolby Atmos and DTS-HD Master Audio
HDMI compatible with DVI
Supports OSD display with instant I/O resolution display
